Device Type |
NAS server |
Host Connectivity |
Gigabit Ethernet |
Total Storage Capacity |
0 GB |
Max Supported Capacity |
108 TB |
Installed Devices / Modules Qty |
0 (installed) / 5 (max) |
Width |
23 cm |
Depth |
22.3 cm |
Height |
16.6 cm |
Weight |
2.7 kg () |
Built-in Devices |
2 x fans |
Processor / Memory |
Processor / Memory |
Processors Installed |
1 x AMD Ryzen Embedded R1600 2.6 GHz |
Number of Cores |
Dual-Core |
Max Supported Qty |
1 |
Max Turbo Speed |
3.1 GHz |
RAM |
8 GB (installed) / 32 GB (supported) – DDR4 |
Features |
ECC |
Storage Controller |
Storage Controller |
Type |
RAID |
Interface Type |
SATA 6Gb/s |
RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
Networking |
Networking |
Data Link Protocol |
10Mb LAN, 100Mb LAN, GigE |
Network / Transport Protocol |
PPTP, L2TP, iSCSI, FTP, CIFS, OpenVPN |
Remote Management Protocol |
SNMP, Telnet, SSH |
Network Services Compatibility |
Microsoft Active Directory (AD), Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV) |
Performance |
Sequential read: 736 MB/s ¦ Sequential write: 796 MB/s |
Features |
Firewall protection, load balancing, wake on LAN (WOL), High Availability, Access Control List (ACL) support, FTP server, surveillance station, DNS server, cloud backup, VPN Server, ONVIF support, Link Aggregation, B-tree file system (Btrfs), file station, EXT4 file system, SSD trim, iSCSI LUN clone/snapshot, RAID migration, Synology Hybrid RAID, automated failover, wake on WAN (WOW), Let’s Encrypt, RADIUS Server, NFS Kerberos authentication, cloud sync, advanced snapshot technology, file and folder-level data restoration, flexible storage quota system, file self-healing, inline compression, SSD read-write cache, shared folder encryption, SMB encryption, login auto block |
Encryption Algorithm |
SSL, TLS, AES-NI |
Compliant Standards |
DLNA CERTIFIED |
Security DVR |
Security DVR |
IP Cameras Supported |
40 |
Compression Format |
H.264, H.265 |
Expansion / Connectivity |
Expansion / Connectivity |
Expansion Bays |
5 (total) / 5 (free) x hot-swap – 2.5″ / 3.5″ |
Expansion Slots |
2 (total) / 2 (free) x M.2 2280 ¦ 1 (total) / 1 (free) x PCI Express 3.0 x2 |
Interfaces |
2 x USB 3.2 Gen 1 – Type A ¦ 4 x Ethernet 1000Base-T – RJ-45 ¦ 2 x eSATA |
Miscellaneous |
Miscellaneous |
Cables Included |
2 x network cable |
Features |
Security lock slot (cable lock sold separately), scheduled power on/off |
Security Slot Type |
Kensington security slot |
Compliant Standards |
VCCI, BSMI, CCC, FCC, RoHS, KC, EAC, RCM, UKCA |
Included Accessories |
Accessory pack |
Power |
Power |
Power Device |
External power adapter |
Voltage Required |
AC 100-240 V (50/60 Hz) |
Power Consumption Operational |
52.06 Watt |
Power Consumption Stand by |
16.71 Watt |
Power Provided |
120 Watt |
Software / System Requirements |
Software / System Requirements |
Storage Operating System |
Synology DiskStation Manager |
Manufacturer Warranty |
Manufacturer Warranty |
Service & Support |
Limited warranty – 3 years |
Environmental Parameters |
Environmental Parameters |
Min Operating Temperature |
0 °C |
Max Operating Temperature |
40 °C |
Humidity Range Operating |
5 – 95% RH |
Sound Emission |
22.9 dBA |
